ZTW Mantis G2 85A ESC 3-8S SBEC For RC Airplane EDF

Sale price$55.99 Regular price$65.87
Save $9.88

We(ZTW) have released a new 32-bit Mantis G2 85A ESC 3-8S SBEC for RC airplane EDF fixed-wing.

Key Features:
1. The holes on both sides of the ESC and the unique fan guard structure make the ESC better heat dissipation.
2. Adopting new generation craft on the MOSFET, low heat generation, withstand large current instantly, and high reliability.
3. Adopting high performance 32 bit microprocessor, stronger computing ability and faster running speed.
4. Super smooth start-up and accurate throttle linearity.
5. Higher driving efficiency and more energy-saving.
6. Two modes: normal and soft acceleration. It is compatible with normal fixed-wing and EDF jet airplanes, please ensure to select the “Soft” acceleration when using EDF jet airplanes.
7. Multiple protections: start-up, over-heat, low-voltage cutoff, over-current and signal loss.
8. Support high RPM motors, and compatible with most motors in the market.
9. Support programming via Phone App or LCD program card, easier and more convenient operation(Extra ZTW Bluetooth Module or LCD program card G2 needed).
10. The ESC has data returning feature, it can send data in real-time: current, voltage, temperature, RPM, throttle and ESC status. And you can check the data via ZTW LCD program card G2 or Phone APP in real-time.

Model Mantis G2 85A 3-8S SBEC
Continuous Current(A) 85 Amps
Burst Current(A) 95 Amps
Voltage 3-8S LiPo/LiHV
Power Wire 12 Gauge 120mm-Red/120mm-Black
Motor Wire 12 Gauge 100mm-Black
BEC Output 6V/7.4V/8.4V Adjustable 8A
Size(not including wires) 88*38*24mm(L*W*H)
Weight 109g
Firmware Upgrade Supported
Model: 85A ESC 3-8S SBEC
Ships From: China
